GUID-E3B0BFE5-49C1-4106-86A0-D4862ABEC4B5
1. Relay K34
2. Relay K41
4.8.6.7 Fuses and relays in the roof electric centre
The fuses and relays in the roof electric centre are listed in the following tables.
The fuse diagram is on the reverse side of the electric centre cover. There is
space for spare fuses. The roof electric centre contains 27 fuses and the nominal
current rating of these fuses is 5-30 A.
4. Maintenance
- 348 -
