IMPORTANT: The maximum allowed input torque for the front PTO gearbox is
1170 Nm and the nominal is 925 Nm.
IMPORTANT: Always make sure that the cardan shaft does not touch the
hydraulic connectors at any working position.
3.17.3.1 Activating and deactivating front power take-off
The front power take-off (PTO) switch is spring-returned and has two positions,
on and off.
GUID-EC84EDD3-BE54-4B4E-89B0-7FB5C525AADC
1. Switch for front PTO
• Start the front PTO by pressing down the switch for front PTO and pulling it
backward.
• Deactivate the front PTO by pressing down the switch for front PTO and
pushing it forward.
3. Operation
- 219 -
