3.13.6.2 Setting automatic side limiters to floating position
You can set the automatic side limiters so that when lowering the linkage, the
side limiter is released to a floating position.
GUID-4CDE4C5B-B4A3-413A-99C2-AF79D4A77346
1. Holding chain
2. Limiting pin
1. Adjust the chain to the length where it will release the side limiter's locking, at
a desired height, while lowering the linkage.
2. Pull out the limiting pin.
3. Adjust the length of the side limiter.
4. Put the limiting pin back to lock the length of the side limiter.
3. Operation
- 188 -
