3.17.3 Front power take-off
Front power take-off (PTO) is only available with front linkage (extra equipment).
GUID-EFBC1015-B082-49CF-B382-6D6D1A1A60EB
1. Front PTO shaft
2. Oil cooler
The front PTO shaft has a diameter of 35 mm with 6 splines. The front PTO is
equipped with a pump inside the housing and an oil cooler to prevent
overheating.
GUID-C61E55BC-7E70-4637-8585-DF36660F0C65
IMPORTANT: The front power take-off shaft's nominal rotating speed is 1000
rpm and the rotating direction is counterclockwise when viewed from the front.
Check that the implement is compatible before attaching.
3. Operation
- 218 -
