6.4 Technically permissible towable masses
Unbraked towable mass (kg) 12000
Independently braked towable mass (kg) 12000
Inertia-braked towable mass (kg) 12000
Towable mass when fitted with hydraulic or
pneumatic braking (kg)
30000
NOTE: The permissible towing device load can reduce the technically permissible
towable mass.
6.5 Tyres
The tyre markings are explained in the following table, tyre 650/65R42 as an
example. See tyre manufacturer's documentation for more details.
650 Tyre section width (inches or millimetres)
65 Aspect ratio
R Construction (R: radial; -: diagonal; B: bias belted)
42 Nominal rim diameter (inches)
168 Load capacity index per tyre (168 = 5 150 kg)
A8 Speed symbol (A8 = 40 km/h)
1.6 Reference pressure (bar)
TL Tubeless (TL) or tube type (TT)
6.5.1 Wheel nut tightening torques
Wheel nut
Tightening torque (Nm)
Front 450
Rear 600
Rim - wheel disc (front and rear) 210
6.5.2 Wheel stud dimensions
Industrial front axle Rear axle
Stud dimension M20x1.5 M22x1.5
Stud length (mm) 43 90
Number of studs per side 10 8
Rear disc
6. Technical specifications
- 383 -
