Valtra T174e A User Manual

1. Fuel gauge
2. Coolant temperature gauge
3. Indicator lights for turn signal
4. Tachometer
5. Speedometer
6. Indicator light for the high beam
7. Proline instrument panel display
The fuel gauge shows the amount of fuel left in the tank.
The coolant thermometer indicates the engine temperature. The zone between
blue (cold) and red (hot) is the normal operating temperature.
2.5.1 Symbols on the Proline instrument panel display
The Proline instrument panel display has fixed views and views that can be
selected by the operator.
Fixed view symbols
The fixed views are the two functions shown on the bottom row of the display:
Symbol Function
Operating hours (hhhh.h)
Clock (hh:mm)
The periodical maintenance symbol is lit on the centre row of the display when
the tractor periodical service must be carried out.
Symbol
Function
Periodical maintenance
Selectable view symbols
The selectable views are the functions shown on the top and centre row of the
display:
Symbol
Function
Working time (h:mm)
Battery charge (V)
cruise
RPM
cruise
KMH
Cruise control
• RPM = engine speed
• KMH = not in use
km/h/mph
Driving speed (km/h/mph)
Rear power take-off (PTO) speed (rpm)
Front power take-off (PTO) speed (rpm)
min
Engine speed (rpm)
l/ha
Avg
l/ha
Immediate fuel consumption (ha, acre)
Average fuel consumption (ha, acre)
Table continued on next page
2. Instruments and controls
- 39 -
