Indicator light Indication
GUID-9ECAC14D-0D4E-4140-A7E0-
EF644A757258
Ʃ-indicator light (optional on models T144, T154, T174E).
The light is lit continuously (yellow) when the tractor is operating in the higher power
range and using PTO.
GUID-578F4FB0-505C-4C35-8A38-
A986A78BBDAF
Glow indicator light.
The light (yellow) is lit when the ignition key is in position II and the engine is cold.
GUID-180F20EC-F75E-4E1F-9232-
EFAB59DA1A6C
Parking brake indicator light
• The light (red) is lit to indicate that the parking brake has engaged
• The light blinks when the parking brake is engaging or disengaging
• The light blinks and the buzzer sounds continuously when there is a fault in the
parking brake
GUID-4E05E947-0AFA-48E8-B011-
E6FBFD3BC3FB
Low fuel level indicator light
The light is lit (yellow) and a buzzer sounds once to indicate that the fuel level is low.
The light blinks if there is water in the fuel.
GUID-7327F975-26FF-444E-
BF66-5428A4842D72
Battery charging indicator light
The light is lit and a buzzer sounds once when battery charging is not ongoing.
IMPORTANT:
A charging failure must be fixed immediately. When the voltage is reduced, the electric
valves may reduce the oil pressure for the multi-disc clutches and cause clutch
slippage which may damage the clutch discs.
2.5.3 Indicator lights on the right side of the display
