3.11.3.4 Speed sensor calibration section
The speed sensor calibration section allows user to calibrate the speed sensor
(optional equipment) when changing the tyre radius. The calibration is required
for the automatic driving modes to work properly.
The speed sensor calibration section consists of two views: menu level and
calibration value.
GUID-2BA8BC2E-8440-4542-B776-CBC17CAA93CB
1. Speed sensor calibration menu
2. Speed sensor calibration value
3.11.3.5 I/O test section
You can view the status of inputs and outputs of the Electrical Control Units
(ECU) in the I/O test section.
The I/O tests are carried out and analysed by the service personnel. The input of
these tests serve as a preliminary information for fault finding.
The I/O test section consists of three views: menu level, the ECU view displaying
the identification number of the ECU and the ECU pin view displaying the status
of selected input/output of the ECU.
3. Operation
- 165 -
