GUID-CE72581A-D3CF-407D-BD72-80BE4FFC74FF
1. Transmission lubrication filter
2. Low pressure filter of the transmission system
Oil filters are located on the right side of the tractor under the cab. The lubrication
filter is indicated with the text LUB on the mounting piece on top of it. The low
pressure filter is indicated with the text TRANS on the mounting piece on top of it.
1. Fit a suitable container under the filter.
2. Clean the filter housing and the surrounding area.
3. Remove the filter housing and the filter element.
4. Wash the filter housing in clean diesel fuel.
5. Lubricate the seal of the new filter element.
6. Fit the new filter into place.
7. Refit the filter housing.
Screw in the housing fully by hand and then unscrew by one quarter-turn.
4. Maintenance
- 303 -
