GUID-3BA6B2A6-1CEE-448C-8A6A-AC4EEC3B8AB0
1. Locking nut
2. Adjusting screw
2. Adjust the adjusting screw.
IMPORTANT: Adjust the adjusting screws on both sides to the same length
so that the turning angle is the same on both sides.
3. Tighten the locking nut.
4.8.9 Cab and shields
4.8.9.1 Cleaning the cab ventilation air filter
Check and clean the cab ventilation air filter when necessary.
WARNING: The air filter element does not remove chemicals from the
outside air. Follow the instructions of the pesticide manufacturer.
NOTE: In extremely dusty conditions the cab ventilation air filter must be cleaned
frequently.
4. Maintenance
- 360 -
