V/f characteristic Factory See
Parameter name Adjusting range default page
A041 Torque boost method selection 00 or 01 00 24
A042 Manual torque boost setting 0,0...20,0 % 1,0 % 24
A043 Manual torque boost frequency point 0,0...50,0 % 5,0 % 24
A044 V/f characteristic setting 00 to 02 00 24
A045
Voltage gain setting 20...100 % 100 % 25
b036
Start reduced voltage selection 00 to 06 00 25
b100
Free adjustable V/f: frequency 1 0...b102 0 Hz 25
b101
Free adjustable V/f: voltage 1 0,0...800,0 V 0,0 V 25
b102
Free adjustable V/f: frequency 2 0...b104 0 Hz 25
b103
Free adjustable V/f: voltage 2 0,0...800,0 V 0,0 V 25
b104
Free adjustable V/f: frequency 3 0...b106 0 Hz 25
b105
Free adjustable V/f: voltage 3 0,0...800,0 V 0,0 V 25
b106
Free adjustable V/f: frequency 4 0...b108 0 Hz 25
b107
Free adjustable V/f: voltage 4 0,0...800,0 V 0,0 V 25
b108
Free adjustable V/f: frequency 5 0...b110 0 Hz 25
b109
Free adjustable V/f: voltage 5 0,0...800,0 V 0,0 V 25
b110
Free adjustable V/f: frequency 6 0...b112 0 Hz 25
b111
Free adjustable V/f: voltage 6 0,0...800,0 V 0,0 V 25
b112
Free adjustable V/f: frequency 7 0...400 Hz 0 Hz 25
b113
Free adjustable V/f: voltage 7 0,0...800,0 V 0,0 V 25
DC brake Factory See
Parameter name Adjusting range default page
A051
Selection of DC braking 00 or 01 00 26
A052
DC braking: frequency 0,00...60,00 Hz 0,50 Hz 26
A053
DC braking: waiting time 0,0...5,0 s 0,0 s 26
A054
DC braking: braking torque 0...70 % 0 % 26
A055
DC braking: braking time 0,0...60,0 s 0,0 s 26
A056
DC braking: edge/level selection 00 or 01 01 26
A057
DC braking: braking torque (start) 0...70,0 % 0 % 26
A058
DC braking: braking time (start) 0,0...60,0 s 0,0 s 26
A059
DC braking: carrier frequency 0,5...12,0 kHz 3,0 kHz 26
b090
Dynamic braking ratio 0,0...100,0 % 0,0 % 29
b095
Dynamic braking selection 00 to 02 00 29
b096
Dynamic braking ON-level 660...760 V 720 V 29
