Operating & Mounting instructions – 8 074 143.03/03 – Page 94
Mounting and Connection
U
VW
PE
Mains supply
external
control cables
EMC earthing
Motor cable with well
screen connection
motor - inverter
Lay motor cables
close together or
screen them !!!
>pDRIVE< CX profi
L1
PE
L3L2
CE-DR Filter
Galvanized steel plate or
aluminium plate or use of a
galvanized mounting plate !!
Connect the screen-bar on a large
area and well conductive
with the mounting plate !!
e.g. with screen-connector
KLBÜ by Weidmüller
AMF
Mains
contactor
Control terminals
Control
Keep distance
>10cm
if possible !!!
Keep distance > 10 cm if possible !!!
PE bar
1+
+
L1
UVW
L2 L3
L
H
O
O2
OI
AM
AMI
FM
P24
TH
PLC
FW
CM1
5
12C
4
12A
3
11C
2
11A
1
ALO
AL1
AL2
Never lay control
and power cables in
the same cable-
channel !!!
Crossings have to
be in a right angle !!!
internal
control cables
