Parameters
Multi speeds − “binary” function
CF1 CF2 CF3 CF4 Adjusted value Parameter
0 0 0 0 Internal preset speed if A001=02 A020
1 0 0 0 Multispeed 1 A021
0 1 0 0 Multispeed 2 A022
1 1 0 0 Multispeed 3 A023
0 0 1 0 Multispeed 4 A024
1 0 1 0 Multispeed 5 A025
0 1 1 0 Multispeed 6 A026
1 1 1 0 Multispeed 7 A027
0 0 0 1 Multispeed 8 A028
1 0 0 1 Multispeed 9 A029
0 1 0 1 Multispeed 10 A030
1 1 0 1 Multispeed 11 A031
0 0 1 1 Multispeed 12 A032
1 0 1 1 Multispeed 13 A033
0 1 1 1 Multispeed 14 A034
1 1 1 1 Multispeed 15 A035
Multispeeds
− “bit” function
SF1 SF2 SF3 SF4 SF5 SF6 SF7 Adjusted value Parameter
0000000Internal preset speed if A001=02 A020
1xxxxxx Multispeed 1 A021
01xxxxx Multispeed 2 A022
001xxxx Multispeed 3 A023
0 0 0 1 x x x Multispeed 4 A024
0 0 0 0 1 x x Multispeed 5 A025
000001x Multispeed 6 A026
0000001 Multispeed 7 A027
A038 Jogging frequency VC 0,00...9,99 Hz 1,00 Hz
The jog function is used for checking, setting or adjusting the application. For this purpose, the
digital command “Jog mode” (see Digital inputs) is available.
A039 Stop mode of jog function VIC 00 to 05 00
Setting Stop-function
00 Idle stop after jog mode Jog mode only
01 Normal deceleration after jog mode possible during
02 DC braking after jog mode Stop status
03 Idle run after jog mode Jode mode also
04 Normal deceleration after jog mode during operation
05 DC braking after jog mode possible
