Operating & Mounting instructions – 8 074 143.03/03 – Page 22
C081
Adjustment 0...10 V input VC 0...9999 Default
C082
Adjustment 4...20 mA input VC 0...9999 Default
C083
Adjustment -10...+10 V input VC 0...9999 Default
C121
Offset-adjustment 0...10 V input VC 0...9999 Default
C122
Offset-adjustment 4...20 mA input VC 0...9999 Default
C123
Offset-adjustment -10...+10 V input VC 0...9999
This adjustments are done in factory and should not be changed!
A019 Multi speed selection VIC 00 or 01 00
Setting Function
00 “binary” function (selection with CF1...CF4)
01 “bit” function (selection with SF1...SF7)
A021 Multi speed 1 VC 0,00...400,0 Hz 0,00 Hz
A022 Multi speed 2 VC 0,00...400,0 Hz 0,00 Hz
A023 Multi speed 3 VC 0,00...400,0 Hz 0,00 Hz
A024 Multi speed 4 VC 0,00...400,0 Hz 0,00 Hz
A025 Multi speed 5 VC 0,00...400,0 Hz 0,00 Hz
A026 Multi speed 6 VC 0,00...400,0 Hz 0,00 Hz
A027 Multi speed 7 VC 0,00...400,0 Hz 0,00 Hz
A028 Multi speed 8 VC 0,00...400,0 Hz 0,00 Hz
A029 Multi speed 9 VC 0,00...400,0 Hz 0,00 Hz
A030 Multi speed 10 VC 0,00...400,0 Hz 0,00 Hz
A031 Multi speed 11 VC 0,00...400,0 Hz 0,00 Hz
A032 Multi speed 12 VC 0,00...400,0 Hz 0,00 Hz
A033 Multi speed 13 VC 0,00...400,0 Hz 0,00 Hz
A034 Multi speed 14 VC 0,00...400,0 Hz 0,00 Hz
A035 Multi speed 15 VC 0,00...400,0 Hz 0,00 Hz
The multispeeds are selected using the digital commands CF1...CF4 or SF1...SF7, which must be
programmed on the terminals first. See Digital inputs.
Multispeeds are pure reference values. The ON and OFF commands are not influenced by the
selection of multispeeds, that means that an additional Start command is necessary for operation
Multispeeds
Multi Speeds
Note:
Multispeeds always override the actual reference value, independent from the setting of
parameter A001.
If no digital input is selected at parameter A001 = 01, the reference value is set using the
analog inputs.
