Operating & Mounting instructions – 8 074 143.03/03 – Page 12
Digital outputs Factory See
Parameter name Adjusting range default page
C021
Function of relay 11 00 to 13 01 46
C022
Function of relay 12 00 to 13 00 46
C026
Function of relay AL 00 to 13 05 46
C031
Relay output 11: Inversion 00 or 01 00 48
C032
Relay output 12: Inversion 00 or 01 00 48
C036
Relay output AL: Inversion 00 or 01 01 48
Output functions Factory See
Parameter name Adjusting range default page
C040
Overload signal output mode 00 or 01 00 49
C041
Level of overload signal 1 0...2 x I
NOM INOM 49
C042
Arrival signal for Acceleration 1 0,0...360,0 Hz 0,0 Hz 49
C043
Arrival signal for Deceleration 1 0,0...360,0 Hz 0,0 Hz 49
C061
Level of thermal motor protection 0...100 % 80 % 50
b034
Run/Power on time 0...9999 0 50
Undervoltage / Autoreset Factory See
Parameter name Adjusting range default page
b001
Selection of restart mode 00 to 03 00 50
b002
Allowable undervoltage time 0,3...1,0 sec 1,0 sec 50
b003
Retry waiting time 0,3...100,0 sec 1,0 sec 50
b004
Undervoltage trip during stop 00 to 02 00 51
b005
Undervoltage Number of retry 00 or 01 00 51
b006
Input phase loss protection 00 or 01 00 51
b007
Matching frequency setting 0,00...400,0 Hz 0,00Hz 51
General functions Factory See
Parameter name Adjusting range default page
F004
Running direction of RUN key read only 00 51
b035
Direction restriciton (input) 00 to 02 00 52
b082
Start frequency adjustment 0,10...9,99 Hz 0,50 Hz 52
b083
Carrier frequency setting 0,5...12,0 kHz 3,0 kHz 52
b086
Frequency converted value setting 0,1...99,9 1,0 52
b087
Selection of STOP key 00 or 01 00 52
b088
After FRS cancelled 00 or 01 00 52
b092
Cooling fan control 00 or 01 00 53
b037
Display selection 00 to 02 00 53
Motor data Factory See
Parameter name Adjusting range default page
H003
Motor kW rating 0,20...75,0 kW Default 53
H004
Motor poles 2 / 4 / 6 / 8 4 53
H006
Motor stabilisation constant 0...255 100 53
