Displays
Alarm messages
The frequency inverter displays alarm messages (= H) if the parameter settings do not match.
Display Meaning
H001 / H201 A061 / A261 > A004 / A204
H
002 / H202 A062 / A262 > A004 / A204
H
004 / H204 A003 / A203 > A004 / A204
H
005 / H205 F001, A020 / A220 > A004 / A204
H
006 / H206 A021 - A035 > A004 / A204
H
012 / H212 A062 / A262 > A061 / A261
H
015 / H215 F001, A020 / A220 > A061 / A261
H
016 / H216 A021 - A035 > A061 / A261
H
021 / H221 A061 / A261 < A062 / A262
H
025 / H225 F001, A020 / A220 < A062 / A262
H
031 / H231 A061 / A261 < b082
H
032 / H232 A062 / A262 < b082
H
035 / H235 F001, A020 / A220 < b082
H
036 A021 - A035 < b082
H
037 A038 < b082
H
085 / H285 F001, A020 / A220 = A063 - A068
H
086 A021 - A035 = A063 - A068
H
091 / H291 A061 / A261 > b112
H
092 / H292 A062 / A262 > b112
H
095 / H295 F001, A020 / A220 > b112
H
096 A021 - A035 > b112
H
110 b100, b102, b104, b106, b108, b110 > b112
b100, b102, b104, b106, b108 > b110
b100, b102, b104, b106 > b108
b100, b102, b104 > b106
b100, b102 > b104
b100 > b102
H
120 b015, b017 > b019
b015 > b017
d090 Warning monitor - read only -
Parameter d090 also displays the actual warnings.
