Operating & Mounting instructions – 8 074 143.03/03 – Page 45
Parameters
C011
Condition of input C001 VIC 00 or 01 00
C012
Condition of input C002 VIC 00 or 01 00
C013
Condition of input C003 VIC 00 or 01 00
C014
Condition of input C004 VIC 00 or 01 00
C015
Condition of input C005 VIC 00 or 01 00
C019
Condition of input FW VIC 00 or 01 00
This parameters define the status of the programmable digital inputs C001 to C005 and FW.
Setting State
00 N.O.
01 N.C.
b098
Thermistor type seleciton VIC 00 to 02 00
Setting Function
00 Thermistor not active
01 Thermistor active (PTC-behaviour)
02 NTC active
b099
Thermistor error level VIC 0...9999 Ω 3000 Ω
This parameter defines the trigger value of the thermistor monitoring.
C085
Standardization of thermistor input VC 0...100 Default
This balance is set in factory and should not be changed.
C101
Reference up/down selecteion VIC 00 or 01 00
Setting Function
00 Does not store value of motorpotentiometer
01 Stores value of motorpotentiometer
C102
Reset function selection VC 00 to 02 00
Setting Function
00 Reset at positive ramp
01 Reset at negative ramp
02 Reset at positive ramp, no effect during operation
If position 00 or 01 is adjusted, a Reset-signal during operation locks the output.
C103
Reset restart function selection VIC 00 or 01 00
Setting Function
00 Restart with 0 Hz
01 Holds the motor during restart
