Operating & Mounting instructions – 8 074 143.03/03 – Page 74

Dimensions

>pDRIVE< CX profi 11 and 15

with option CE-DR 400/28

without filter RFI-filter incl. line choke

189

7

210

>50

260

246

170

>pDRIVE<

CX profi

170

7

210

>50

306

286

>pDRIVE<

CX profi

255

229

250

7

>50

390

376

190

>pDRIVE<

CX profi

210

7

250

>50

436

416

>pDRIVE<

CX profi

300

>pDRIVE< CX profi 18 to 30

with option CE-DR 400/56

without filter RFI-filter incl. line choke
