Operating & Mounting instructions – 8 074 143.03/03 – Page 53
Parameters
H003
Motor kW rating VIC 0,20...75,0 kW Default
H004
Motor poles VIC 2 / 4 / 6 / 8 4
With this parameters the nominal motor data according to the type plate are adjusted.
H006
Motor stabilisation constant VC 0...255 100
With the help of this parameter the drive can be stabilized. If the motor does not run roundly, the
value must be increased. If the inverter operates a motor with higher power than the inverter, the
value must be reduced.
Motor data
Motor data
2nd Set
2nd Set-up
A203 2nd Base frequency VIC 30...400 Hz 50 Hz
Adjustment of the base frequency. The base frequency is the frequency at which the output voltage
reaches its maximum value. Normally, the base frequency is equal to the nominal motor frequency
(more information see parameter A003).
A204 2nd Maximum Frequency VIC 30...400 Hz 50 Hz
Adjustment of maximum frequency. Between base frequency and maximum frequency the output
voltage is constant (field suppression).
F202 2nd Acceleration ramp VC 0,01...3600 s 30 s
Setting of required acceleration time. The time is in reference with the range from 0 Hz to maximum
frequency (parameter A204).
b092
Cooling fan control VIC 00 or 01 00
Setting Function
00 Fan is alway running
01 Fan runs only during operation
(after mains switch-on and after stop-command the fan still runs 5 minutes)
b037
Display selection VIC 00 to 02 00
This parameter must be always set to 00.
