1.) see parameter b031
2.) If such parameters are adjusted, no start command is accepted during adjustment.
Impulse contacts and retained commands will be ignored as long as the inverter is still in setting
mode.
Rechtslauf/forward Linkslauf/reverse Stop
Operating & Mounting instructions – 8 074 143.03/03 – Page 16
Description of parameters
The parameters of the >pDRIVE< CX are arranged and described according to their functions.
The following example explains the attributes of parameters:
A038 Jogging frequency VIC 0,0...9,9 Hz 1,0 Hz
Group of parameter
Number of parameter
Name of parameter
Adjusting range
Factory default
Parameter description:
adjustable only
if software lock is open 1.)
adjustable in pulse lock state 2.)
parameter is adjustable
Display actual values
d001 Output frequency - read only -
Displays the output frequency on the LED display.
If this display mode is selected, the Hz-LED right of the display lights up.
d002 Output current - read only -
Displays the motor current on the LED display.
If this display mode is selected, the A-LED right of the display lights up.
d003 Direction of rotation - read only -
Displays the direction of rotation on the display.
d004 PID controller feedback - read only -
Displays the actual PID controller value scaled using parameter A075.
Display = Feedback PID controller x A075
If the PID controller is not active, the display shows:
