Operating & Mounting instructions – 8 074 143.03/03 – Page 28

Note:

The DC brake causes a heating of the connected motor.

Be sure that the motor does not get to warm.

DC brake controlled via digital input (A051=00)

The DC brake is activated via a digital input (D8: C001...C005=7).
