Technical Data
>pDRIVE< CX profi 11 15 18 22 30 37
Power data
Motor rating (recomended) 11 kW 15 kW 18,5 kW 22 kW 30 kW 37 kW
Continuous output power 15,2 kVA 20,1 kVA 25,3 kVA 29,4 kVA 39,4 kVA 48,4 kVA
Continuous output current 22 A 29 A 37 A 43 A 57 A 70 A
Nom. input current
without line choke 24 A 32 A 40 A 47 A 63 A 76 A
with line choke 21 A 28 A 36 A 42 A 56 A 68 A
Maximum current 120 % I
N
(>60 s / 10 min); 150 % I
N
for 0,5 s
Starting torque > 150% T
N
General data
Input voltage 3 AC 380...480 V ±10%; 50/60 Hz ±5%
Output voltage 3 AC, 0...100 % of mains voltage
Output frequency 0,1...400 Hz, adjustable
Base frequency 30...400 Hz, adjustable
Losses at 100% I
N
600 W 800 W 975 W 1150 W 1550 W 1900 W
at 70% I
N
435 W 575 W 700 W 820 W 1100 W 1350 W
Weight approx. 5 kg 12 kg 20 kg
Dimensions Height 260 mm 390 mm 540 mm
Width 210 mm 250 mm 310 mm
Depth 170 mm 190 mm 195 mm
Design / Protection degree Built-in unit for vertical mounting / IP20
Operating/Storage temp. -10...+40°C / -20...+65°C
Temperature increase +50°C with max. 2 kHz carrier frequency
Pollution degree 2 according to EN 50178
Cooling forced
Humidity 20...90%, non-condensing
Altitude ≤1000 m (above: power reduction of 1% per 100 m; max. 2000 m)
Braking function
Braking torque 80% with 60% with 10% without option 10% without
BR60R BR60R option
Internal braking unit built-in −−
External braking option BS 400/27 with BS 400/27 with BR20R BS 400/27
2 x BR60R parallel with BR20R
DC braking f, t and I adjustable
