Projecting
General technical data
Standards CE-EMC directive in connection with optinal RFI filter and under
consideration of the installation remarks
CE low voltage directive, UL
Product standard EN 61 800-3 “Power drive system”
NSR directive 73/23 EWG
Vibration/ Shock 5,9 m/s² (0,6 G) 10...55 Hz (CX profi 37: 2,94 m/s² (0,3 G))
Protection class class 1 in accordance with EN 50178
Environmental class 3K3 in accordance with DIN IEC 721-3-3
Overvoltage class III in accordance with EN 50178
Frequency resolution digital: 0,1 Hz, analog: f
MAX
/1000
Frequency stability digital ±0,01 % of f
MAX
; analog ±0, 2 % of f
MAX
Reference voltage +10 V, max. 20mA
Auxiliary voltage +24 V, max. 100 mA
Control method V/f - characteristic, PWM sine modulated
V/f-characteristic U/f-characteristics for constant and squared increasing torque;
output voltage, base and maximum frequency
base frequency adjustable
Carrier frequency 3 kHz, 0,5...12 kHz adjustable
Control Keypad or terminals
Analog input O 0...+10 V, R
i
= 10 kΩ
Analog input O2 -10...+10 V, R
i
= 10 kΩ
Analog input OI 4...20 mA, R
i
= 100 Ω
Digital input FW +24 V, positive/negative logic
Digital input 1...5 +24 V, positive/negative logic
Thermistor input R
i
= 10 kΩ
PWM output FM 0...10 V; max. 1 mA
Analog output AM 0...10 V; max. 2 mA
Analog output AMI 4...20 mA
Relay output AL max. 250 V AC
Relay output 11 max. 250 V AC
Relay output 12 max. 250 V AC
Protection functions for overcurrent, over- and undervoltage, earth fault, trip of fan,
overload, electronic motor protection
Options RFI footprint filter with line choke, output motor filter AMF
isolating amplifier TV5 / TV6
Busoption GW-PBO2 Gateway for Profibus DP
