Operating & Mounting instructions – 8 074 143.03/03 – Page 92
without AMF 100m 100m 100m 100m 100m 100m
with 1 AMF 200m 200m 200m 200m 200m 200m
with AMF (one type bigger) 250m 250m 250m 250m 250m 250m
without AMF 60m 60m 60m 60m 60m 60m
with AMF 120m 120m 120m 120m 120m 120m
without AMF 75m 75m 75m 75m 75m 75m
with 1 AMF 150m 150m 150m 150m 150m 150m
with AMF (one type bigger) 200m 200m 200m 200m 200m 200m
without AMF 50m 50m 50m 50m 50m 50m
with AMF 80m 80m 80m 80m 80m 80m
without AMF 20m 20m 20m 20m 20m 20m
with AMF 35m 35m 35m 35m 35m 35m
Filter (incl. line choke) CE-DR 400/28 400/28 400/56 400/56 400/56 400/68
AMF (Output-Motor-Filter) AMF 450/48 450/48 450/48 450/48 450/90 450/90
typical motor cable mm² 3x6² 3x6² 3x10² 3x10² 3x10² 3x16²
1st environment (domestic premises)
unrestricted to every person
1st environment (domestic premises)
restricted to qualified persons
2nd environment (industrial premises)
Maximum distance Inverter - Motorwithout standards
screened
unscreened
Multiplicationfactors:
8 kHz instead of 4(5) kHz switching frequency all values x0,7 2 motors parallel with 2 long cables all values x0,4
16 kHz instead of 4(5) kHz switching frequency all values x0,5 3 motors parallel with 3 long cables all values x0,25
4 motors parallel with 4 long cables all values x0,15
2 motors parallel with 1 long cable all values x0,8 5 motors parallel with 5 long cables all values x0,10
(distribution near the motor)
Maximum allowed distance
(single motor cable length)
Frequency inverter - Motor
Maximum distance Inverter - Motor
CX profi 11
CX profi 15
CX profi 18
CX profi 22
CX profi 30
CX profi 37
Allocation table: Inverter - Options - Motor cables - Motor
