Yamaha F25A - Flywheel Magneto Installation; Starter Hub Installation

5-6
POWR
E
FLYWHEEL MAGNETO
Flywheel magneto installation
1. Install:
● Flywheel nut
Å For USA and CANADA
ı Except for USA and CANADA
CAUTION:
The major load should be applied in the
direction of the arrows. If the load is not
applied as shown, the flywheel holder may
easily slip off.
Flywheel holder:
YB-06139/90890-06522
T
R
.
.
Flywheel nut:
157.0 Nm
(16.0 m • kgf, 115.8 ft • lb)
Å
ı
Starter hub installation
1. Install:
●
Starter hub
Universal clutch holder:
YM-91042/90890-04086
