P1036102-007 ZXP Series 7 Card Printer Service Manual 289
7
Replacement Procedures for the
High-Capacity Output Hopper
Introduction
The following section describes removing the high-capacity output hopper option for
a ZXP Series 7 Pro printer ONLY with and without a laminator; and, where applicable,
sub-assemblies and/or components that are considered replaceable on the high-
capacity output hopper.
For a complete listing of Spare Part Kits and Upgrade Kits available for the
Zebra ZXP Series 7 Card Printer, see the ZXP Series 7 Spare Parts Catalog at
www.zebra.com/parts.
Electric Shock • Before performing any of the procedures in this section, set the
printer power to OFF (O) and disconnect the power cord.
Electrostatic Discharge • All replacement procedures must be performed at a static-
free work station, an anti-static wrist strap must be worn and properly terminated, or
other appropriate protection must be used.
Caution • Before beginning any of the procedures that follow, read completely
through the procedure. If you do not have the specified tools or if any step(s) seem
beyond your skill or experience level, do not attempt the procedure. You may cause
additional damage to the printer.
Note • Some of the photographs in this section may show additional parts removed in
addition to removals for the process being described.
