P1036102-007 ZXP Series 7 Card Printer Service Manual 365
Cleaning
Cleaning the Printer
Polish the Printhead
Note • Use is password protected and limited to Zebra-authorized service personnel.
The Advanced Cleaning button in the Clean Printer section of the ZXP Toolbox
provides access to printhead polishing. When printhead polishing is enabled in the
ZXP Toolbox, printhead polishing can be done via the OCP.
Step 1. Enable printhead polishing in the ZXP Toolbox
Step 2. Press the MENU button on the Operator Control Panel (OCP). The OCP will
display the Main Menu.
Step 3. Scroll through the Main Menu, and select Advanced Settings. The OCP will
display the Advanced Settings Menu.
Step 4. Scroll through the Advanced Settings Menu, and select Clean Printer. The
OCP will display the Clean Printer Menu.
Step 5. Open the printer cover and ribbon drawer, remove the ribbon, and press
Next.
Step 6. Close the ribbon drawer and printer cover, and press Next.
Step 7. Insert a Polishing Card (grit up) in the Manual Feed Slot, and press Clean.
Step 8. Wait until the cleaning process completes. The card will be ejected through
the same slot.
Step 9. Replace the ribbon, and press Next to return to the Advanced Settings
Menu.
Note • Clean the Card Path (page 363) is recommended after printhead polishing to
remove any loose debris from the printer.
