Replacement Procedures
for the Printer
Introduction
The following sections describe removing both major assemblies and—where
applicable—sub-assemblies and/or components that are considered replaceable.
In general, only removal directions are presented. Unless otherwise noted,
replacement would be performed by reversing the removal steps. Replacement
instructions for some common or simple procedures are not presented.
For a complete listing of Spare Part Kits and Upgrade Kits available for the Zebra ZXP
Series 7 Card Printer, see the ZXP Series 7 Spare Parts Catalog at www.zebra.com/
parts.
Electric Shock • Before performing any of the procedures in this section, set the
printer power to OFF (O) and disconnect the power cord.
Electrostatic Discharge • All replacement procedures must be performed at a static-
free work station, an anti-static wrist strap must be worn and properly terminated, or
other appropriate protection must be used.
Caution • Before beginning any of the procedures that follow, read completely
through the procedure. If you do not have the specified tools or if any step(s) seem
beyond your skill or experience level, do not attempt the procedure. You may cause
additional damage to the printer.
Note • Some of the photographs in this section may show additional parts removed in
addition to removals for the process being described.
