Zebra ZXP 7 series Service Manual

P1036102-007 ZXP Series 7 Card Printer Service Manual 49
Replacement Procedures for the Printer
Procedures: OCP PCBA
OCP PCBA
Step 1. With a TORX T10 driver, remove the five screws holding the Faceplate to the
Options Cover;.
Step 2. Set the Faceplate aside.
Step 3. With a TORX T10 driver, remove the two screws holding the OCP PCBA to
the Options Cover.
