116
DRIVE OF AGRICULTURAL MACHINERY
F13BN018 FH13N016
ENGAGEMENT OF REAR PTO SHAFT – DEPENDENT REVOLUTIONS
The number and the direction of the revolutions are dependent on the engaged gear and the position of reversing lever. The posi-
tion of reduction lever does not have any influence on the number rear PTO shaft revolutions in dependent revolution mode.
With engine running:
1. Rear PTO shaft dependent revolutions are selected by PTO shaft revolutions preselection lever.
2. Speed of rear PTO shaft starting preselection switch (1) is not functional in this mode.
3. Rear PTO shaft switch (3) is not functional in this mode.
4. Select applicable revolutions by rear PTO shaft selection switch (2).
5. Engage gear by the main gear shifting lever and the direction of drive by reversing lever. When tractor drives off, rear PTO shaft
also spins.
Automatic PTO clutch disengagement is not functional in this mode.
