78
DRIVING OPERATION
FH12N058 FH12N047 FH12N054
THREE-GEAR TORQUE MULTIPLIER
Three-gear multiplier is a standard
equipment of all types of tractors
Shifting individual gears of three-gear
multiplier is controlled by two buttons on
the head of main gear shifting lever
H -
Increasing travel speed
L -
Decreasing travel speed
It is done without travel clutch pedal de-
pressed (under load).
SIGNALIZATION OF MULTIPLIER
FUNCTION
Individual engaged gears of multiplier are
signalized by a sign (1) in the left upper
corner of the display.
The highest gear (the fastest)
Middle gear
Lowest gear (the slowest)
INCREASING, DECREASING THE
TRAVEL SPEED BY TWO GEARS
2xH
Increases the travel speed by two
gears
2xL
Decreases the travel speed by
two gears
