161
BALLAST WEIGHTS
F_02_26 E552a
FRONT WEIGHTS
Front weights
Combination
of weights
(pcs)
Mass of weights
(kg)
2+2 4x50 200
3+3 6x50 300
5+5 10x50 500
7+7 14x50 700
The front weights of the can type are
suspended in the tool carrier. They are
protected from lateral movement with a
pin inserted between the central weights.
The other weights are attached to the
central ones with two clamps.
Note: After the insertion of the pin the
front weights and the weight carrier can
be used as the front hook for emergency
towing of a sunken tractor.
WEIGHT OF THE FRONT THREE-
POINT HITCH
Material Weight mass
(kg)
Concrete 290
Cast-iron 460
Concrete 800
