ACQUAINTANCE WITH THE TRACTOR
DASHBOARD
DESCRIPTION
A - controls
B - coolant thermometer
C - fuel gauge
D - pressure gauge
E - speedometer
F - display
CONTROLS AND BUTTONS
When switching the key in switchbox
from “0” position to “1” position, all con-
trols light up.
1 - High beam lights (blue). Lights up
with high beam lights on.
2 - Tractor turn signal indicator (green).
3 - Turn indicator control of 1
st
trailer
(green).
4 - Turn indicator control of 2
nd
trailer
(green).
5 - Minimum air pressure in brake sys-
tem control (red). It is lit up with the
pressured drop for air brakes of trail-
er under the critical interval i.e. 450
kPa.
6 - Manual brake (red). It is lit with en-
gaged manual brake.
7 - Charging (red). With engine run,
lights up with charging disorder. If the
engine is at standstill, it must be lit.
8 - Lubricating (red). With engine running
lights up with the oil pressure drop
under 120 to 60 kPa. If the engine is
at standstill, it must be lit up
9 - Air cleaner clogging (yellow). Lights
up with air filter clogging.
10 - (not connected).
11 - (not connected)
12 - (not connected)
13 - Indicator (red) of a failure in the hy-
drostatic control system. It lights with
engine operation in hydrostatic control
failure. If the engine is at standstill, it
must be lit up.
14 - (not connected)
15 - Diesel particle filter control
(red), for more see “Driving
operation”
16 - Diesel particle filter control
(green) , for more see chapter „Driving
operation“
17 - Engine ignition (yellow). Signalizes
the activity of device for easement of
the start of the engine
18 - (not connected)
19 - Fuel (orange). It lights up with the
remaining 1/6 - 1/10 of the volume of
the tank.
20 - Gearbox disorder control (red), for
more see “Driving operation” chapter
21 - Gear box oil filling overheating con-
trol (red), for more see chapter “Driv-
ing operation”
22 - Gearbox switchboard delivery filter
clogging control (red), see “Driving
operation” chapter for more infor-
mation
23 - Rolling up in the menu button
24 - Rolling down in the menu button
25 - entry to the menu button, confirming
items on the menu
26 - LCD backlight inversion button
27 - Reset button hours of operation and
km
28 - Change of display button (road,
PTO, Moto hours, km).
