201
MAINTENANCE INSTRUCTIONS
F_02_107 XF_02_141 F_02_114
REPLACING THE FILTRATION
ELEMENT OF THE HYDROSTATIC
STEERING
1 - Dismantle the left rear side plate of
the hood
2 - Place a suitable container under the
hydrostatic steering tank
3 - Release the drain screw
4 - Drain oil from the tank
5 - Unscrew the tank lid
6 - Replace the filtration element
7 - Install the new element
8 - Disconnect both the hoses from the
working cylinder and together with
the return hose insert their ends to a
waste oil container.
9 - Start the engine and at the idle
speed (max. 10 s) turn the steering
wheel 2-3 times to both sides to
push oil out of the steering unit and
the pipes.
