MAIN TECHNICAL PARAMETERS
LOAD-BEARING CAPACITIES OF THE REAR TYRES
Tyre dimen-
sions
Travelling speed
40 km.h
-
1
30 km.h
-
1
20 km.h
-
1
8 km.h
-
1
Tyre load-bearing
capacity (kg)
Tyre load-bearing
capacity (kg)
Tyre load-bearing
capacity (kg)
Tyre load-bearing
capacity (kg)
Tyre
1 pc
Axle
Infla-
tion
(kPa)
Tyre
1 pc
Axle
Infla-
tion
(kPa)
Tyre
1 pc
Axle
Infla-
tion
(kPa)
Tyre
1 pc
Axle
Infla-
tion
(kPa)
16.9-34
1900 3800 170 2380 4760 170 2750 5500 170 3330 6660 170
16.9R34
2430 4860 160 2600 5200 160 2750 5500 150 3400 6800 150
18.4-34
2050 4100 140 2565 5130 140 2750 5500 120 3400 6800 130
18.4R34
2750 5500 160 2750 5500 160 2750 5500 120 3400 6800 120
16.9-38
2060 4120 170 2575 5150 160 2750 5500 150 3400 6800 160
16.9R38
2575 5150 160 2750 5500 160 2750 5500 130 3400 6800 130
18.4-38
2170 4340 140 2715 5430 140 2750 5500 110 3400 6800 110
18.4R38
2750 5500 140 2750 5500 140 2750 5500 110 3400 6800 120
480/70R38
2750 5500 150 2750 5500 150 2750 5500 110 3400 6800 110
520/70R38
2750 5500 120 2750 5500 120 2750 5500 90 3400 6800 90
600/65R38
2750 5500 80 2750 5500 80 2750 5500 60 3400 6800 80
The load-bearing capacity values refer to the rear-wheel track of 1725 mm.
Note: The 480/70R38 tyre is a dimensional equivalent of the 16.9R38 tyre. The 570/70R38 tyre is a dimensional equivalent of the
18.4R38 tyre.
The specified inflation values are minimum valued adapted to the current tyre load so that the tyre deformation can remain in the
range in which all the operation requirements are met.
During operation on a hard base it is suitable with regard to slippage and abrasion of the tyre to increase the pressure by 30 kPa.
