228
MAIN TECHNICAL PARAMETERS
MAIN DIMENSIONS OF THE TRACTOR (MM)
Tractor type FORTERRA HSX note
Tyre dimen-
sions
Front 14,9R24
Rear 580/70R38
Outline length with hitches with the front
three-point hitch lowered 5100 without ballast weights
Outline length with hitches without the front
three-point hitch 4520 without ballast weights
Width over the rear fenders 2270
Height to the exhaust outlet 2766
Tractor height to the upper cab edge 2766
Inner height under the front axle support 520
Height of the mouth of the stage hitch in the
top position (mouth centre) 915
Wheel base 2590
