Technical data 151
Supply cable fuses
Fuses for short circuit protection of the supply cable are listed below. The fuses also
protect the adjoining equipment of the drive in case of a short circuit. Check that the
operating time of the fuse is below 0.5 seconds. The operating time depends on the
supply network impedance and the cross-sectional area and length of the supply
cable. See also chapter
Planning the electrical installation.
Note: Fuses with a higher current rating must not be used
1Φ AC supply
3Φ AC supply
Drive type
MFE190-04xx...
Input
current
(A)
IEC fuse UL fuse Cross-sectional
area of cable
Rated
current
(A)
Voltage
(V)
Class Rated
current
(A)
Voltage
(V)
UL
Class
mm
2
AWG
-01A6-2 3
20
500 gG
20
600
CC
1.5...4 16…12
-03A0-2 7 500 gG 600 1.5...4 16…12
-06A0-2 14 500 gG 600 1.5...4 16…12
-09A0-2 20 500 gG 600 1.5...6 16…10
Drive type
MFE190-04xx...
Input
current
(A)
IEC fuse UL fuse Cross-sectional
area of cable
Rated
current
(A)
Voltage
(V)
Class Rated
current
(A)
Voltage
(V)
UL
Class
mm
2
AWG
-01A6-2 2
20
500 gG
20
600
CC
1.5...4 16…12
-03A0-2 4 500 gG 600 1.5...4 16…12
-06A0-2 8 500 gG 600 1.5...4 16…12
-09A0-2 12 500 gG 600 1.5...6 16…10
