Technical data 157
Dimensions and weights
For basic weights and dimensions, see Main dimensions on page 35.
Ambient conditions
Environmental limits for the drive are given below. The drive is to be used in a heated,
indoor, controlled environment
.
Operation
installed for stationary
use
Storage
in the protective
package
Transportation
in the protective
package
Installation site altitude 0 to 2000 m (6560 ft) above
sea level. [See also section
Altitude derating on page
149.]
--
Air temperature
1.6 A model:
0 to +50 °C (32 to 122 °F)
3 A, 6 A, 9 A models:
0 to +55 °C (32 to 131 °F).
No frost allowed.
See section Derating on
page 149.
-40 to +70 °C
(-40 to +158 °F)
-40 to +70 °C
(-40 to +158 °F)
Relative humidity 0 to 95% Max. 95% Max. 95%
No condensation allowed. Maximum allowed relative humidity is 60%
in the presence of corrosive gases.
Contamination levels No conductive dust allowed.
The drive must be installed
in clean air according to
enclosure classification.
Cooling air must be clean,
free from corrosive materials
and electrically conductive
dust.
Sinusoidal vibration:
EN 60068-2-6: 2008
Tested according to,
mechanical conditions:
2…9 Hz: 3.0 mm (0.12”)
9…200 Hz: 1g
––
Shock:
EN 60068-2-27: 2009
IEC 60068-2-27:2008
– Max. 10g, 11 ms Max. 10g, 11 ms
Free fall Not allowed 76 cm (30”) 76 cm (30”)
