Accessories 183
Cables
A wide range of motor and feedback cables are available.
 Motor power cables
For easier installation, it is recommended that a color-coded motor power cable is
used. The part number for a BSM rotary motor power cable is derived as follows:
CBL 025 SP -12 S
m ft
1.5 5*
2.5 8.2
3.0 10*
5.0 16.4
6.1 20*
7.5 24.6
9.1 30*
10 32.8
15 49.2
15.2 50*
20 65.6
22.9 75*
30.5 100*
RP
SP
WP
S
-
6
12
20
35
50
90
BSM style threaded motor
connector (motor end only)
Raw cable
(no connector)
Current
(Amps)
Standard
connector
Stainless
connector
* North America only
Larger motors requiring 35 A cable or greater normally use terminal box connections, so a motor power connector is
not required. For this reason connectors are not available on 35 A - 90 A cable.

Examples:
A 6.1 m cable, with a CE threaded standard connector, rated for 12 A has part number CBL061SP-12.
A 30.5 m cable, with a CE threaded stainless steel connector, rated for 20 A has part number CBL305SP-20S.
A 50 ft cable, with no connector, rated for 50 A has part number CBL152RP-50.
SDM style threaded motor
connector (motor end only)
