ABB MicroFlex e190 User Manual

Operation principle and hardware description 29
 Layout - top
Ethernet fieldbus ports (page 74)
PE connection
(page 53)
Memory unit (page 32)
 Layout - bottom
X8 voltage output selector (page 78)
Optional 24 V
control circuit
supply input
(page 56)
Incremental encoder feedback input
(page 83)
