184 Accessories
 Feedback cables
The part number for a feedback cable is derived as follows:
CBL 020 SF -E 1 S
RF
DF
WF
SF
D
B
E
S
A
1
-
2
S
-
m
ft
2.5
8.2
5.0
16.4
7.5
24.6
10
32.8
15
49.2
20
65.6
30
98.4
R
Raw cable Standard
connector
Stainless steel
connector
Incremental
encoder
EnDat
SinCos
BiSSBSM servo motor
feedback cable with at
least 1 connector
Raw cable
(no connector)
Other lengths available on request
Example:
A 2 m encoder feedback cable for a MicroFlex e190 drive, with required connectors at both ends, has part number
CBL020SF-E2.
Legacy
controllers
e100 / e150
e180 / e190
SSI
Smart Abs
Servo motor feedback
cable with drive
connector only
SDM servo motor
feedback cable with at
least 1 connector
Resolver
These feedback cables have the outer shield tied to the connector housing(s). If you
are using an alternative cable with your chosen feedback device, be sure to obtain a
cable that is a shielded twisted pair 0.34 mm
2
(22 AWG) wire minimum, with an
overall shield. Ideally, the cable should not exceed 30.5 m (100 ft). Maximum wire-to-
w
ire or wire-to-shield capacitance is 50 pF per 300 mm (1 ft) length, to a maximum of
5000 pF for 30.5 m (100 ft).
 Ethernet cables
The cables listed in this table connect MicroFlex e190 to other Ethernet nodes such
as the controller, additional MicroFlex e190s, or other Ethernet compatible hardware.
T
he cables are standard CAT5e shielded twisted pair ‘crossover’ Ethernet cables:
Cable description Part Length
mft
CAT5e Ethernet cable CBL002CM-EXS
CBL005CM-EXS
CBL010CM-EXS
CBL020CM-EXS
CBL050CM-EXS
CBL100CM-EXS
CBL200CM-EXS
0.2
0.5
1.0
2.0
5.0
10.0
20.0
0.65
1.6
3.3
6.6
16.4
32.8
65.6
