96 Start-up
Start Mint WorkBench
Mint WorkBench is a fully featured application for programming and controlling the
MicroFlex
e190. Mint WorkBench includes a comprehensive help file that contains
information about every Mint keyword, how to use Mint WorkBench, and background
information on motion control topics. Press F1 to display the help file. For help on
using Mint WorkBench, click the red Mint WorkBench icon on the opening page.
1. On the Windows Start menu, select All Programs, ABB, Mint WorkBench, Mint
WorkBench. (Windows 8.1: On the Apps screen, click the Mint WorkBench icon.)
2. In the opening dialog box, click Start Online Project...
3. Wait until the MicroFlex e190 is listed in the Controllers found box, e.g.
“MicroFlex e190 on 192.168.0.1”.
4. Select the MicroFlex e190 in the list, and check Launch Commissioning Wizard.
5. Click Select.
Note: If the MicroFlex e190 is not listed, check the Ethernet cable is connected to the
E3 port on the front panel of the drive, not E1 or E2 on the top panel. Check that the
MicroFlex
e190 is powered correctly and the start-up sequence (see Power on
checks, above) has completed. Ensure you have enabled the Ethernet adapter for
Mint WorkBench (see page 95). Click Scan to re-scan the ports. It can take up to 5
seconds for Mint WorkBench to detect the MicroFlex e190.
6. Mint WorkBench connects to the MicroFlex e190 and displays the Commissioning
Wizard.
Note: If Launch Commissioning Wizard was not checked, Edit & Debug mode is
displayed.
