ABB MicroFlex e190 User Manual

154 Technical data
DC input (supply) connection
Motor connection
Brake resistor connection
Voltage 270...340 V DC ±10%
Ratings
Drive type
MFE190-04xx...
I
dcN
(A)
C
(µF)
-01A6-2 1.96 560
-03A0-2 3.67 560
-06A0-2 7.35 1120
-09A0-2 11.02 1120
I
dcN
is the average DC input current requirement.
Terminals
Detachable screw terminal block for 0.20...6 mm
2
wire.
Motor types Asynchronous induction motors, asynchronous servo motors,
synchronous permanent magnet motors
Frequency 0...550 Hz
Current See section Ratings.
Switching frequency 8 kHz
Maximum motor cable
length
50 m (164 ft) with screened cable
Terminals
Detachable screw terminal block for 0.20...6 mm
2
wire.
Description Unit All models
Nominal switching threshold V DC on: 388, off: 376
Nominal power
(10% peak power, r = 57 Ω
kW 0.25
Peak power
(10% peak power, r = 57 Ω
kW 2.7
Maximum brake switching current A
pk
10
Minimum load resistance Ω 39
Maximum load inductance µH 100
