ABB MicroFlex e190 User Manual

28 Operation principle and hardware description
 Layout - front
Motor feedback input (page 76)
Motor output
(page 51)
DC supply connection
(page 54)
AC supply connection
(page 51)
Fieldbus status LEDs (page 111)
7-segment display (page 114)
Fieldbus mode selectors (page 75)
Start-up function selectors (page 72)
Safe Torque Off inputs (page 187)
Digital inputs / outputs (pages 64-71)
Analog inputs / output (page 61-63)
PC host Ethernet connection (page 75)
Earth bar
Brake resistor
connection (page 171)
Option card (page 182)
Encoder breakout (page 180)
Resolver adapter (page 181)
