ABB STT04 User Manual

EBTH TEMPERATURE TRANSMITTER
CALIBRATION
B - 9
METER VALUE ADJUSTMENT
Use this function to adjust the four to 20 milliampere output of the field
device using values from an external current meter. This method is
only valid for HART devices.
Key Display Comments
This operation will cause a change in output not cor-
responding to the input. Be sure the control loop is in
manual.
Select YES.
Select D-TO-A ADJUST.
Select METER VALUE ENTRY.
Use the number keys to enter the current meter
reading.
Use the number keys to enter the current meter
reading.
CALI-
BRATE
OUTPUT WILL BE
AFFECTED! PROCEED?
NO
→ YES
ENTER
CALIBRATION
→ D-TO-A ADJUST
BENCH CALIB.
ENTER
D/A CAL USING
UPDOWN ARROW KEYS
→ METER VALUE ENTRY
ENTER
4 mA CALIBRATION:
ENTER METER VALUE
4.000
ENTER
20 mA CALIBRATION:
ENTER METER VALUE
20.000
ENTER
ID TAGNAME
READY
