OPERATING PROCEDURES
OPERATIONAL FUNCTIONS
4 - 16
Monitor Key Functions
The monitor key functions slightly vary, based on the device. An
example of the PTS transmitter is explained in this section.
Use the monitor function key to monitor:
• Primary output.
• Primary input.
• Secondary engineering units.
• Temperature of cell.
NOTES:
1. For details about monitor key functions, refer to Monitor Key
Functions in Appendix A.
2. A device must be connected to the terminal in order to use the
monitor key functions.
MONITOR PRIMARY OUTPUT
This function allows output monitoring of the field device. The output
is displayed in percentage of the calibrated range.
Key Display Comments
Select PRIMARY OUTPUT.
The output is displayed in percentage of the cali-
brated range. The display is updated every second.
Press to exit the monitor input function.
MONITOR
→ PRIMARY OUTPUT
PRIMARY INPUT
SECONDARY UNITS
TEMPERATURE
ENTER
ID TAGNAME
PRIMARY OUTPUT:
nnn.nn%
GOOD STATUS
CLEAR
CLEAR
ID TAGNAME
READY
