REPAIR/REPLACEMENT AND UPGRADE
RECOMMENDED SPARE PARTS
6 - 6
7. Click Start on the personal computer and open the ABB-STT04
program group.
8. Double click the STT04 DownLink Software icon.
9. Click Special Advanced and select Upgrade Firmware. The
upgrade process takes several minutes.
10. Turn off the STT04 terminal and disconnect the RS-232-C cable
from the STT04 terminal and PC.
11. Turn the STT04 terminal on. Check the revision number of the
start-up screen to verify that the upgrade was successful.
RECOMMENDED SPARE PARTS
Table 6-2 lists the recommended spare parts for the STT04 terminal.
Use the kit or part number to order components from your ABB sales
representative.
Table 6-1. Upgrade Languages
Language STT04 Key Sequence
English Hold down and and press
.
French Hold down and and press .
Spanish Hold down and and press .
German Hold down and and press .
1 ↑
On
2 ↑
On
3 ↑
On
4 ↑
On
Table 6-2. List of Spare Parts
Part Number Description
Clip Leads cable
Part number 1948517?4
STT04 communication cable.
Battery Pack
Part number 1949646?1
Powers the terminal.
Antistatic
Part number 1948385?1
Contains static-dissipative work surface and
ground cord assembly (wrist bands and
alligator clips).
Recharger
Part number 1949616?1
Battery charger
Input: 110 VAC, 50/60 Hz.
Output: 9 VDC, 100 mA.
NOTE:
1. For non-U.S. standard applications, use a charger that produces 9 VDC, 100 mA, similar to LCR
Electronics Inc. part number AD0910B2-PN4 (220).
