600T & 600T EN PRESSURE TRANSMITTER
CALIBRATION
Q - 26
Set Output %
Key Display Comments
This operation will cause a change in output not cor-
responding to the input. Be sure the control loop is in
manual.
Select YES.
Select SET OUTPUT %.
If digitally configured, the D-TO-A ADJUST selection
will not appear.
Select LOW and press
. (Procedure for
HIGH selection is identical).
Display indicates present data.
Enter LOW value,
.
CALI-
BRATE
ENTER
OUTPUT WILL BE
AFFECTED! PROCEED?
NO
→ YES
[ 3 TIMES ]
ENTER
CALIBRATION
SENSOR TRIM
D-TO-A ADJUST
PV BIAS
→ SET OUTPUT %
ENTER
SET OUTPUT %
→ LOW
HIGH
ENTER
ENTER
OP %: nnn.nn %
PV VAL:
value units
Hit ENTER to set OP%
ENTER
ENTER NEW VALUE
value %
ENTER
ENTER
ID TAGNAME
READY
