ABB STT04 User Manual

TROUBLESHOOTING
ERROR MESSAGES
5 - 5
TEMP SLOPE
WARNING
TB82 High or low temperature
slope
Verify sensor wiring connections and
inspect cable for shorts. Remove all poten-
tial shorts to ground, conduit or metals.
Verify that sensor had 10 to 15 min. to accli-
mate to temperature environment to which it
was calibrated.
Disconnect temperature compensator leads
from transmitter and measure resistance.
Replace sensor with spare when transmitter
does not accept calibration values.
USER TEMP HI/LO
ALARM
EBTH Cell temperature over/
under user alarm limit.
Correct temperature problem.
Change alarm value. Refer to configuration
procedures for EBTH TEMPERATURE
TRANSMITTER in Appendix B.
Table 5-2. STT04 Error Messages for ABB FSK Devices
Message
Affected
Device
Probable Cause Corrective Action
CALIBRATION
REQUIRED
PTS Cell has not been
calibrated with present
amplifier assembly.
Calibrate the field device. Refer to the
calibration section of the appropriate PTS
pressure transmitter instruction.
EQS Field device needs to be
calibrated.
Calibrate the field device. Refer to the
calibration section of the appropriate
EQS temperature transmitter instruction.
CANNOT SAVE,
CONFIGURATION
TOO LARGE
STT Transmitter type not sup-
ported by STT terminal
revision level.
Consult ABB to obtain latest STT terminal
revision.
CELL
CHARACTERIZATION
BOARD
EEPROM FAILURE
PTS Damage to cell
characterization board.
Turn the STT terminal off and then on. If
error still exists, replace cell (refer to
repair/ replacement section of the appro-
priate product instruction for procedure).
CELL
TEMPERATURE
OVER USER ALARM
PTS
EQS
Cell temperature over/
under user alarm limit.
Correct temperature problem.
Change alarm value. Refer to configura-
tion procedures for EQS TEMPERA-
TURE TRANSMITTER in Appendix C or
PTS PRESSURE TRANSMITTER in
Appendix E.
CELL
TEMPERATURE
UNDER USER ALARM
CELL TEMPERATURE
OVER LIMIT
PTS Cell temperature input is
over/under factory speci-
fied limits.
Remove the source of temperature
extreme.
CELL TEMPERATURE
UNDER LIMIT
COMMAND ABORTED STT Cancel key pressed
before function was com-
pleted.
Try function again.
COMMUNICATION
ERROR
STT Noisy signal. Check terminal wiring and eliminate
source of noise.
Table 5-1. STT04 Error Messages for HART Devices (continued)
Message
Affected
Device
Probable Cause Corrective Action
