ABB STT04 User Manual

XM/SM/XE MAGNETIC FLOWMETER
CALIBRATION
I - 5
CALIBRATION
This section details the calibration functions of the STT04 terminal
while interfacing an XM/SM/XE Mag Flow Meter. There are two types
of calibration functions:
• Empty pipe detector.
• D-to-A adjust.
NOTES:
1. When calibrating, a field device must be connected to the
STT04 terminal.
2. To change calibration or configuration parameters of a field
device that is connected to an IMFBS01 module, the transmitter
must be taken off-line. This is done at the INFI 90 OPEN console.
Refer to Figure I-2 for an overview of the calibration functions.
Make a selection using the arrow keys.
Make a selection using the arrow keys.
Specify values using the number keys. The UNITS
displayed will be those designated in a previous
screen. After entering a value press .
Make a selection using the arrow keys.
Key Display Comments
ENTER
FLOW DIRECTION:
→ FWD AND REV
FWD ONLY
ENTER
EMPTY PIPE DET.:
→ OFF
ON
ENTER
UPPER PV ALARM
nnn.nn UNITS
LOWER PV ALARM
nnn.nn UNITS
ENTER
ENTER
STORE THIS
CONFIGURATION?
NO
→ YES
ENTER
ID TAGNAME
READY
